Power Supply Unit for Pedalboards

• Specially designed for installation and seamless integration with existing Harley Benton Spaceship 40 pedalboards
• Can also be mounted under some pedalboards of other brands
• 7 Individually insulated and 4 non-insulated outlets
• AC circuit 100 - 240 V Universal input voltage operation
• High current capacity for modern digital effects
• LED display on each output
• Total power: 31.5 W
• Dimensions (H x W x D): 30 x 450 x 50 mm
• Weight: 570 g

7 Isolated outputs to eliminate hum and noise:

• 2x 9 V / 250 mA
• 3x 9 V / 500 mA
• 2x 9 / 12 / 18 V - 500 mA

Additional non-isolated outputs:

• 1x 9 V / 3 A for the power supply of effects with high power consumption and multi-FX devices
• 1x 24 V / 2 A
• 1x USB-A for power supply and charging tablets and smartphones
• 1x USB-C
• 24 V output connection to additional power supply units

Included Accessories

• 2 x Aluminium edges for mounting the powerbar and crossbars of existing Harley Benton Spaceship 40 boards
• 1 x AC power cable / 1.2 m
• 3 x 30 cm DC cable
• 3 x 60 cm DC cable
• 3 x 90 cm DC cable
• 1 x Cable for reverse polarity
• 1 x Battery clip
• 1 x DC 2.5 mm / DC 5.5 mm cable
• 1 x DC / 3.5 mm mini-jack cable
• 1 x Voltage boost cable
• 1 x Current boost cable
• 1 x EIAJ-05 cable
• 1 x Cable fixing set
• 1 x Hexagon wrench 5mm
• 1x Hook and loop straps 100 x 45 mm
• 6 Screws
• 2 Rubber feet
